1961 1962 1963 1964 1965 Cadillac (See Details) Dual-Core Radiator REPRODUCTION

$409.00
SKU
6165ACCR6164OL

REPRODUCTION

INTERNATIONAL SHIPPING IS AN ESTIMATE.

REPRODUCTION. You are purchasing a dual-core radiator with cap included. This radiator has a straight lower hose connection. Originally for 1961-1962 models, the lower radiator hose outlet was curved up due to the frame. This radiator will still work for 1961-1962 models, however the original molded style hoses will need to be bent to fit or a flex style hose can be used. The downflow is located to the left of the radiator. Please carefully compare to yours to ensure proper fit, paying attention to inlet and outlet positions.

Please select the check box above if you would like to add a fan and shroud.  The shroud is aluminum. The quiet reversible electric fan is 16 inches with an air flow volume of 2600 CFM. The fan is approximately 3.5 inches thick when mounted.

You can also add an electronic fan temperature sending unit relay kit. This is not needed to install the electronic fan as custom wiring can be done to use a personally installed toggle switch on the dash. This thermostat kit is to help the fan function automatically by measuring the engine temperature. At about 180 degrees F this will signal the radiator fan to function and turn on.

These radiators are made from uncoated aluminum, due to the manufacturing process they may come with some dings and scratches that will not affect the performance of the radiator.

ATTRIBUTES:

Radiator Core Size: 25 Inches X 17 Inches X 2.5 Inches

Radiator Inlet Connector Size: 1.5 Inches

Cap/Top Inlet Inner Diameter: 1.625 Inches

Radiator Outlet Connector Size: 1.75 Inches

Top Hose Outlet Inner Diameter: 1.375 Inches

Material: 100% Aluminum

FITS:

1961-1964 Cadillac Models**

1965 Cadillac Series 75 Limousine Models ONLY

**PLEASE NOTE: For 1961-1962 models some modification for the lower hose connection would be required as note above.
